ZSK Web API

Example for two lines of text

POST

This Json example will create stitch data which two lines of text, as shown below.

Parameters

Parameter	Type	Description	Required
`LineSpacing`	double	Line space between the two text lines in mm	No

Example

{
	"RequestType": "CreateTC",
	"Monograms": [
		{
			"Text": [
				"Line 1"
			],
			"FontFamily": "Times New Roman",
			"FontSizeMM": 10.0,
			"UsedNeedle": 1,
			"TextStitchParameter": "Premium"
		},
		{
			"Text": [
				"Line 2"
			],
			"FontFamily": "Arial",
			"FontSizeMM": 12.0,
			"UsedNeedle": 3,
			"TextStitchParameter": "Premium"
		}
	],
	"Needle": [
		{
			"Red": 0,
			"Green": 0,
			"Blue": 0,
			"ColorName": "Black",
			"ColorNumber": "20",
			"ThreadSize": "40",
			"Name": "ISACORD"
		},
		{
			"Red": 255,
			"Green": 255,
			"Blue": 255,
			"ColorName": "White",
			"ColorNumber": "15",
			"ThreadSize": "40",
			"Name": "ISACORD"
		},
		{
			"Red": 0,
			"Green": 164,
			"Blue": 90,
			"ColorName": "kelly",
			"ColorNumber": "5515",
			"ThreadSize": "40",
			"Name": "ISACORD"
		}
	],
	"LineSpacing": [
		5.0
	],
	"ServerVersion": 3
}
